FEA Modeling of Complex Bolted Joint Systems
We use FEA to model real bolted joints—preload, contact, gaskets, and thermal growth—to predict clamp, slip, and bolt fatigue and deliver torque/angle specs with validation plans.
What this solves
- Preload you can trust: Convert torque to tension with realistic friction, sequence, and embedment—then verify with Strain-Gauged Bolts and Torque Tension Testing woven into the plan.
- Leakage, loosening, and fatigue mitigation: Map per-bolt load share, identify opening/slip, and quantify stress range that drives failure; update coatings and policies through Fastener Specification Consulting.
- Thermal & materials effects: Address ΔT and CTE mismatch (e.g., aluminum–steel stacks) with seating strategies that hold in hot zones; validate in Product Validation & Testing.
- Closed-loop correlation: Feed measured mean/range and rainflow histograms back into the model via Field & Lab Data Acquisition to hit correlation targets and freeze the spec.
When to use this service
- Multi-bolt patterns with uneven stiffness (covers, split lines, flanges, brackets)
- Gasketed or coated joints where embedment and relaxation erode preload
- Hot, high-vibration, or shock-loaded environments (aftertreatment flanges, turbo interfaces)
- Programs under warranty pressure needing measured evidence and a defendable spec
How we model your joint
Inputs & assumptions
Bolt grade/size/thread, head/washer stack, interface geometry; friction (underhead/thread/joint), lube/coat; gasket compression/relaxation; material curves and CTE; duty cycles and acceptance criteria.
Pretension representation
Use pretension elements for system-level clamp or explicit thread models where local root stress matters; confirm repeatability with Torque to Yield Tests when appropriate.
Contacts & mesh
Frictional contacts at underhead, joint, and gasket with separation allowed where realistic; refined solids at underhead radii, holes, and fillets; convergence check at hot-spots.
Sequencing
Preload → embedment/settling → service loads/pressure → thermal cycles → unload; tune increments and stabilization for robust convergence.
Validation loop
Instrument critical bolts with Strain-Gauged Bolts, synchronize with torque–angle and temperature via Field & Lab Data Acquisition, and finalize specs in Product Validation & Testing. When custom fixtures are needed, we design Specialized Test System Design to match the model.
Deliverables
- Joint model & report: per-bolt clamp, contact pressure maps, opening/slip margins, bolt stress range & predicted life
- Specification package: torque/angle targets, tightening sequence, after-paint torque policy, re-torque schedule
- Validation addenda: DVP&R block (thermal/shaker/pressure), instrumentation plan, sampling & sync details
- Correlation memo: friction and gasket curve calibration, contact settings, and agreed validation targets
Technical options
- Threads vs pretension elements (local stress vs system clamp)
- Gasket modeling using compression curves and seating stress targets
- Thermal modeling with ΔT and CTE mismatch across the stack
- Mean-stress models for fatigue (e.g., Walker) aligned to measured spectra
- DAQ integration for torque–angle, strain, temperature, and CAN signals
Example applications
- Engine aftertreatment flange (hot zone): clamp retention through thermal cycles; washer/lube stack optimization
- Gearbox cover (asymmetric): secondary bending reduction; tightening sequence that rebalances load share
- Pump flange with elastomer gasket: seating stress validation; slip margin under pressure pulsing
- Bracket to cast housing: mixed bending; pattern redesign to remove two “hot” bolts
FAQs
Do we need to model threads explicitly?
Only when local root stress, underhead geometry, or micro-geometry is the life driver; otherwise, pretension elements capture system-level clamp efficiently.
How do you handle friction variation?
We bound μ with measured ranges, confirm via Torque Tension Testing, and set angle strategies (or Torque to Yield Tests) when repeatability is critical.
Can this include loosening/relaxation effects?
Yes—embedment and relaxation steps are part of the sequence; we’ll prescribe after-paint torque and re-torque policy where needed.
How do we know the model is right?
We correlate against Strain-Gauged Bolts and duty cycles captured in Field & Lab Data Acquisition, targeting ±20–30% on critical responses before freezing the spec.
